Graphic Format Supported:AI, BMP, DST, DWG, DXF, DXP, LAS, PLT, Other
CNC or Not:Yes
Cooling Mode:Water Cooling
Place of Origin:Anhui, China (Mainland)
Machine table Features
1. Gantry dual drive, adopting advanced gear rack transmission structure. Equipped with grinding gear and rack, and through the precision collimator one time metering assembly. The machine will secure long-term high cutting speed, high precision transmission.
2. The machine table machined by large planomiller, with high temperature annealing twice, and high strength complete welding, customer will have long-term payback.
professional CNC controller introduction
1. Support different images format as Al, DXF, PLT, Gerber, can read standard ISO G codes from MaterCam, Type3 such nesting software.
2. Automatically optimization when open or lead in DXF file, like delete repeated line, merge connected lines, recognize in/out cutting file and file sorting out.User can decide to manually do above work, or let controller do it automatically.
3. Support conventional picture edit functions
4. Following what you see is what you get, to set lead in/out, kerf compensation, merge, bridge, over burning, save gap ….etc
5. Unique function of Preview of cutting work flow.
6. Support segmental pierce, Progressive pierce, Pre-pierce, power pierce,,, separately setting output laser watt, frequency, laser type, air type, pressure, auto cutting height during pierce and cutting.
7. Support to set separate lead in/out speed according to adjustment of laser power.
8. Big storage, allowing user to save all cutting parameters to use it again on same material.
9. Breakpoint recovery, CNC can return to the point where the cutting stopped, allowing partial file cutting. It can go to any point to start there after stop or pause.
10. Same software can support round tube cutting and plate cutting, programming is same, and support intersect cutting.
11. Support to cut at set height, automatically seek edge, and start from outside of workpiece, or lift up when torch is out of workpiece.
12. Powerful expanding capability, over 15 PLC process programming, over 30 programmable processes.
13. Input/output and alarm input are programmable, support wireless remote control, and support internet ……
More functions, please contact us for instruction manual.
CNC control language
Besides English, we have professional Russian, Spanish,German language, we can also support local agent to translate any language in need.
Laser power option
IPG: 500,700, 1000, 1500, 2000, 3000, 4000, 6000, 8000,10000W, 12000W
Trumpf : 2000W, 3000W, 4000W, 6000W, 10000W,
Raycus: 500, 750, 1000, 1500W,
Machine size:3015, 4015, 4020, 6015, 6020. 6023, 6025, 6525, 8020, 8025, 9520, 12025, 13030…..We customize as your metal sheet size.
Machine type: Single table, auto feeding shuttle table,
Enclosed table, open table all available,
Plate and tube cutting table, tube cutting machine available,
Service after sales
A. Machine will be supplied with training video and user's manual in English for installation, operation, maintenance and trouble-shooting, and shall give technical guide by e-mail, fax, telephone, skype….
B. We offer technician to customer's site for installation and training, customer shall cover visa, ticket, local living cost.
C. Customer may come to our factory for training. We will offer training of installation, operation, machine trouble-shooting, and maintenance.
D. We offer life-long technical service for all our machines.
Warranty and service
Laser power: Two years warranty, Guaranteed by laser power manufacturer
Qiaolian Machine table: Ten years warranty, Guaranteed by Qiaolian
Electronics and motion parts: One year warranty, Guaranteed by parts manufacturer
Free Warranty Service: We will send replacement parts on our cost first, keep customer's machine running is top concern.
If machine needs onsite service for quality issue, we send technician to anywhere on our cost. You may inquire any of our old international customers for reference!
Product's real warranty rely on the original parts manufacturer, not the machine manufacturer. We can NOT offer warranty that we are unable to fulfil it. We dont play for one-time business.
Many China factories offer cheap price and 2 or 3 years warranty, but during warranty period, you can really get free replacement and onsite service?
Or they tell you need to pay expensive international express, and stop your machine, wait long time for return damaged parts to repair and replacement?
Or they're busy, currently have no technician to your site for old machine service?
Cheaper price never goes together with better service..........
You will get what you paid for........ it always makes sense.
