Graphic Format Supported:AI
Cutting Thickness:2mm ss, 4mm cs, 2mm gs
CNC or Not:Yes
Cooling Mode:Water Cooling
Control Software:Shanghai WEIHONG
Place of Origin:Anhui, China (Mainland)
Laser type:fiber laser
Laser power:200W 300W
Applicable material:stainless steel, carbon steel, galvanized sheet, iron
Max cutting thickness:2mm ss, 4mm cs, 2mm gs, 2mm iron
Running speed:Max 25m/min
The max load for worktable:300KG
Working power:≤1800W, 220V, 50/60HZ, 3 phase
This machine is designed for advertising to cut metal including 0-2mm stainless steel, 0-4mm carbon steel, 0-2mm galvanized sheet and 0-2mm iron.
It applies Taiwan PMI ball screw, YYC gear and rack as the transmission and Shanghai WEIHONG servo motors as the drive.
The 1.5t weight machine body and our advanced technique makes the machine run very stably when it runs at high speed.
Above all, the economical but good quality machine is very suitable for ad industry clients to cut thin metal for making channel letters.
CNC Control system
Double Shanghai WEIHONG servo motors
Taiwan HIWIN linear rail, YYC gear and rack
Laser lens and mirror
Water chiller CW-6000, Exhaust device, Protective mirror
Rotary axis to cut round or square pipe
2. Technical parameters
White & Yellow (can be changed as per your request)
200W or 300W
stainless steel, carbon steel, galvanized sheet, iron
Max cutting thickness
2mm ss, 4mm cs, 2mm gs, 2mm iron
Stroke of X axis
Stroke of Y axis
Stroke of Z axis
The max load for worktable
≤1800W, 220V, 50/60HZ, 3 phase
Oxygen or Nitrogen
Machine worktable is milled by CNC milling machine which ensures the worktable on the same level and deviation within 0.01mm. It won't be out of shape during a long time.
1. The whole machine we offer one year guarantee time free, without consumable parts replacement and man-made fault
2. User-friendly English manual and video CD for machine using and maintaining
3. My company English software can do all kinds of pattern recognition,software upgrading and updating free
4. You are the one we CARE ABOUT!We always offer you our best service no matter when and where
1.What are the other characteristics of the machine besides high cutting speed ?Can it carve small chest card ?
Large power ,processing power smooth operation .It can carve small chest card
2.Can it carve both wood and metal ? Can it cut or relief ?
Yes, it depends on metallic materials .It can carve wood , aluminum ,cooper and iron with the machine and sink .it can cut and relief
3.Does it work stability ?Will there be small problems ? Is it suitable for a long time work .
Yes , stable work .there won't be any problems It is suitable for a long time work .security performance.
4.What ‘s the other auxiliary equipment? Will you give me polishing machine with the engraving machine .
Computer and processing equipment .We can provide free polishing machine if the price is reasonable.
5.Is engraving machine spindle coolong method water cooling or air cooling ? Are there dust cover or industry vacuum cleaner ?
Generally speaking .water cooling for advertising . woodworking engraving for air cooling .According to custom’s request .We can provide the dust cover and industry vacuum cleaner with the machine .But you have to pay for it .
6.What is in the need of maintenance? What kind of lubricating oil is suitable ?
The transmission part .the rail section .We suggest to use sewing machine oil to clean spindle .
7.What ‘s the other auxiliary equipment ?
We suggest the machine equipped suitable SPB regulator .Prevent summer lighten.It’s easy to follow processing .to prevent the damage caused by the machine’s instability
8 .What’s the difference between screw carving and rack carving .
|Difference||Screw carving||Rack carving|
|Processing plate||Small power||Large power|
9 .What’s the difference between circular rail carving machine and square rail carving machine ?
|Difference||Circular rail carving||Square rail carving|
|Operation guide||Circular rail||Square rail|
