Cutting Speed:0-40000mm/min
Graphic Format Supported:AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Application:Laser Cutting
Condition:New
Cutting Thickness:0-30mm
CNC or Not:Yes
Cooling Mode:Air Cooling
Control Software:Leetro
Place of Origin:Anhui, China (Mainland)
Brand Name:ACCURL
Certification:CE, ISO
Name:CNC Laser Cutting Machine
Product name:400w 500w 1000w 2000w Protected Metal fiber laser cutting machine
Laser power:500W / 1000W / 2000W / 3000W
Laser tube:IPG or Raycus fiber laser generator
Keyword:Fabric Laser Cutter
Function:Cutting Metal Materials
Type:Laser Machining
Model:APEX-1325
Color:Blue
Working area:1300mmX2500mm
After-sales Service Provided:Engineers available to service machinery overseas
Function Advantages:
1. Excellent quality of light beam
2. Highly cutting speed: the 2 times by co2 laser cutting machine under the same power.
3. Very high stability and efficiency of photoelectric conversion
4. Very low using cost and maintenance cost
5. Convenient product operation and maintenance
6. Very strong soft optical effects: compact volume and structure
7. Gantry double driving structure, high damping machine tool bed, good rigid,
8.This model adopts imported AC servo system driver and imported transmission system, the moving structure of machine tool adopts imported gear and rack transmission, linear guide track for guiding, ensuring the high speed,high precision and high reliability of equipment.
9. Rack and guide adopt fullly enclosed protective device, which prevents oil free friction movement and dust pollution, enhances using life of transmission parts and ensures the precision of machine tool movement.
10. Professional laser cutting machine, cnc control system, computer operation, can ensure the cutting quality, and more convenient for cutting work.
11. Automatic swiching table configuration, which shortens the standby time, and effectively enhances the working efficiency more than 30%.
12. Fully enclosed protective cover,using safety.
| Fiber laser cutting machine parameter | |||||
| Laser Type | Imported Original Fiber Laser | ||||
| Laser Wavelength | 1060nm | ||||
| Laser Maximum Power | 500W | 1000W | 2000W | 3000W | 4000W |
| Max. Cutting thickness | ≤8mm | ≤12mm | ≤16mm | ≤18mm | ≤20mm |
| Total Power Consumption | <14KW | <18KW | <22KW | <26KW | <30KW |
| Working Size | 1500X2500mm/1500X3000mm/2000X4000mm | ||||
| Max.cutting speed | 0-30m/min(Depending on the material and thickness) | ||||
| X, Y, Z Axis Orientation Precision | ≤±0.05mm/m | ||||
| X, Y, Z Axis Repeat Precision | ≤±0.03mm /m | ||||
| Min line width | ≤0.15mm | ||||
| Maximum Empty Running Speed | 120m/min | ||||
| Driving way | Imported servo motor | ||||
| Transmission way | Y-axis import gear rack double driver, X-axis imported ball screw | ||||
| Worktable Max Load | 1600 KGS | ||||
| Cooling System | Water Cooling | ||||
| Continous working time | 24 Hours | ||||
| Environment temperature | 0-35°C | ||||
| Power requirements | 380V/3 Phases /50Hz or 60Hz | ||||
| Power requirements Outer size (L*W*H) | 4500x2000x1800mm | ||||
FAQ
1. How can i make sure that this machine is suitable for my work?
A: You can describe what you will use this machine to do , such as your working materials, max working area and cutting thickness, We will give you right machine for your work
2. Are you factory or trading company?
We are factory and we have Import and export rights, There are many clients coming here to visit our factory every year ,
You are welcomed to come to our factory at any time
3. It is my first time to use this machine , is it easy to operate?
We have manual book and operation video, it can teach you how to use it .
If there is still have any question, we can teach you online
If there is a need , Our engineer can go abroad to help you
4. What can i do if the machine have any problems after i get it?
Free parts will be sent to you during warranty period
Free after-sales service will be given in the machine lifetime, we offer you 24hours online service
