Specifications
Cutting Speed:80000mm/min
Graphic Format Supported:DXF
Application:Laser Cutting, stainless steel, aluminum, copper, iron, etc.
Condition:New
Cutting Thickness:0-40mm
CNC or Not:Yes
Cooling Mode:Water Cooling
Control Software:Shanghai Cypcut high grade
Place of Origin:Anhui, China (Mainland)
Certification:CE, ISO, SGS
Machine body:Heavy duty full-welded steel honeycomb structure
Rotary axis diameter size:0-160mm(can be customized)
Laser power:500w to 4000w
Laser source:Raycus/ IPG
funcation:cutting for pipe and plate
Optional:Full cover/ rotary axis for cylinder/ changable tables
Motor:Japan Yaskawa servo motor
Guider:Taiwan HIWIN
Screw:Taiwan TBI
After-sales Service Provided:Engineers available to service machinery overseas
ackaging & Delivery
Packaging Details
Wooden Carton with Polybag inside
Lead Time :
Quantity(Sets) 1 - 20 >20
Est. Time(days) 10 To be negotiated
Application Material:
Commonly used for both pipe and plate in carbon steel, stainless steel, spring steel, galvanized steel, aluminum, copper, brass, iron, and other metal sheet.
Application Industry:
Metal cutting processing, electrical switch manufacturing, aerospace, food machinery, textile machinery, engineering machinery, locomotive manufacturing, agriculture and forestry machinery, elevator manufacture, special vehicles, household appliances, tools processing, IT manufacturing, oil machinery, food machinery, diamond tools welding, gear welding, metal materials surface treatment, decoration advertising, laser processing services and other kinds of machinery processing industry, etc.
Machine Parameter:
| Model | genius-KJG-1530D |
| Working Size | 3000x1500x∅160mm (other size can be customized) |
| Max idling Speed | 80M/min |
| Repeated Positioning Accuracy | ± 0.025mm |
| Laser Power | 500W-4000W |
| Machine body | Heavy duty full-welded steel honeycomb structure |
| Machine Gantry | Whole aluminum casting gantry |
| X,Y axis transmission | Taiwan YYC high precision m2 bevel slanting rack |
| Z axis transmission | Taiwan HIWIN double nuts auti-gap ball srew |
| Guider | Taiwan HIWIN square guider |
| Bearings | Japan NSK |
| Driving motor | Japan Yaskawa 1500W servo motor |
| Laser source | Raycus/ IPG |
| Laser power | 500w/750w/1000w/1500w/2200w/3300w/4000w |
| Water chiller | Suitable for laser power |
| Power Supply | 380V ±5% 50HZ |
| Whole Machine Weight | 5500KG |
How to chose a good quality machine?
1. The machine must with heavy duty and stabable machine body, without shake in high speed processing, ensure the machine accuracy;
2. Reasonable design, our machine with six Intelligent partitioned ventilation system, saving the electric power; with grined oil guider to ensure the oil recycling without leakage.
3.Good spareparts, all of our sparrparts are original, such as Taiwan HIWIN guider, Taiwan TBI ball screw, French Schneider Electric, etc. Stability machine body + good quality spareparts+Strict installation technology=Good quality machine.
