Specifications
Cutting Area:1300*2500mm /1500*3000mm
Cutting Speed:30-50m/min
Graphic Format Supported:AI, PLT, DXF, BMP, DST, DWG, LAS, DXP
Application:Laser Cutting
Condition:New
Cutting Thickness:1-6mm (500w model )
CNC or Not:Yes
Cooling Mode:Water Cooling
Control Software:Cypcut/NC Studio
Place of Origin:Anhui, China (Mainland)
Brand Name:ACCURL
Certification:CE, SGS, CCC
Warranty:3 years, 3 year
Keyword:laser cutting machine metal
Min Line Width:0.1mm
Driving system:Servo Motor
Positioning Accuracy:±0.03mm
Max moving speed:100m/min
Power:500w 750w
Laser source:Raycus /IPG
Machine Weight:2000kg
Dimensions:4.5*2.45*1.95M
Product Description
Main Feature:
1)Working Area 3000*1500mm /1300*2500mm (other special size can be customized )
2)Fiber power:300W /500w/750w
500w Fiber laser cutting machine metal is the best cutting tool for thin sheet metal cutting (<6mm ) especially for stainless steel and carbon steel cutting, which is mainly applied in advertising industry.
500w laser cutting machine for metal sheet Parameters
Material | Thickness (mm) | Max cutting speed (m/min) | Auxiliary Gas
|
Carbon Steel | 0.5 | 18 M | Oxygen |
1 | 10 M | ||
2 | 6 M | ||
3 | 3 M | ||
4 | 2.5M | ||
5 | 2m | ||
Stainless steel | 0.5 | 18 M | Nitrogen |
1 | 12 M | ||
2 | 5 M | ||
3 | 3 M | ||
4 | 2.5M | ||
5 | 2M |
Advantages
500w laser cutting machine for metal sheet Unique Features
1. High efficiency: high-speed digital motion control by Germany technology system, especially for high-speed, high-precision laser cutting.
2. Integrated design: a 10% reduction of the volume of space, easier and cheaper for ocean and inland transportation.
3. Stable running: adopting gantry structure with synchronous bilateral gear and rack drive, and high-strength aluminum beams enhance its stability.
4. Low energy consumption: photoelectric conversion rate is up to 25-30% which can save energy and power. Electric power consumption for this type fiber cutting machine is only about 20%-30% of the traditional Co2 laser cutting machine.
5. High technology:full application of laser technology, mechanical technology, numerical control technology and other advanced technology.
6. Stable worktable and 20 years usage life.
7. Easy to maintain and cutting surface is smooth, no burr, saving time and labor.
8. This machine is economy and competitive.
9. Low maintenance cost: 500w fiber laser cutting machines doesn't need reflect lens, saving much maintenance cost. The key components lifespan can reach 100,000 hours with stable performance.
laser cutting machine for metal sheet Technical Data :
| Laser Type | Fiber Laser | |
| Laser Power | 300W 500W 750w | |
| Laser Source | Germany Import Laser Fiber Laser Source | |
| Laser Technology | Germany Technology | |
| XYZ Working area | 1500*3000*150mm | 1300*2500*150mm |
| Max. Cutting Thickness (CS) | 1mm - 6mm | |
| Max. Cutting Speed | 30-50 Meters / Min (up to materials) | |
| Max. Location speed | 60m/min | |
| Laser wavelength | 1070nm | |
| Minimum line width | ≤0.1mm | |
| Location precision | ≤±0.05mm | |
| Re-location precision | ±0.02mm | |
| Max. moving speed | 100m/min | |
| Supporting Format | PLT, DXF, BMP, AI | |
| Power demand | 220V/50Hz | |
| Cooling Way | Water Cooling | |
| Worktable max. load | 1000KGS | |
| Transmission Method | Ball Screw Transmission | |
| Table-driven system | Japanese Imported Yaskawa Servo Motor & Driving System Taiwan Hiwin/KH Precision Gear Track Taiwan Hiwin/KH precision Ball Track | |
| Focus Method | Following and Automatic Adjust Focus | |
| Control Method | Offline Movement Control | |
| Control software | Perfect Laser Professional Laser Cutting Software | |
laser cutting machine for metal sheet Application
Applied materials
Fiber cutter is mainly used for carbon steel cutting, mild steel, stainless steel, silicon steel, aluminum alloy, titanium alloy, galvanized steel sheet, pickling board, aluminum zinc plate, copper and many kinds of metal materials. It is an cnc laser cutters can be used to do high precision cutting. It also can be called fiber cutter machine,fiber optic laser cutter,laser cutter for metal,fiber cutter,carbon steel cutting,cnc laser cutters.
Applied Industry
This Fiber Laser Cutting Machine is applied in sheet metal processing, aviation, spaceflight, electronics, electrical appliances, subway parts, automobile, machinery, precision components, ships, metallurgical equipment, elevator, household appliances, gifts and crafts, tool processing, adornment, advertising, metal foreign processing various manufacturing processing industries.
